Product Summary

The SS51T is a Surface Mount Sensor. It is operated by the magnetic field from a permanent magnet or electromagnet. The small SOT89 style package surface mounts on PC boards and flexible circuits. The SS51T uses an industry standard "gull wing" design which makes it less susceptible to "solder bridging" and allows increased circuit board density. The SS51T package can accommodate larger IC’s than SS1 and allows for fourpin designs.

Parametrics

SS51T absolute maximum ratings: (1)Supply Voltage: -28 V to +28 V; (2)Voltage externally applied to output: -0.5 V to +28 V; (3)Output ON Current: 20 mA; (4)Operating Temperature Limits: -40℃ to +150℃; (5)Storage Temperature Limits: -40℃ to +150℃.

Features

SS51T features: (1)Wide temperature and voltage ranges for design flexibility and harsh (automotive) environments; (2)resistant to thermal and mechanical stress; (3)lower than other SOT-89 packages; (4)allow the customer to reduce the total gap; (5)Industry standard "gull-wing" design; (6)Less susceptibility to "solder bridging"; (7)Allow increased circuit board density; (8)Bipolar, unipolar and latching magnetics; (9)Low Gauss versions available for high accuracy or wide gap applications; (10)allow 4-pin package designs.

Diagrams

SS51T block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
SS51T
SS51T
Honeywell
Board Mount Hall Effect / Magnetic Sensors 4.5Vdc to 24Vdc Magnet Position Sens
Data Sheet
0-1: $1.14
1-10: $1.09
10-50: $0.98
50-100: $0.90
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
SS511AT
SS511AT
Honeywell
Board Mount Hall Effect / Magnetic Sensors 5V 10mA Bipolar Hall-Effect Sensor
Data Sheet
0-1: $1.10
1-10: $0.89
10-50: $0.75
50-100: $0.61
SS511A-T
SS511A-T
Honeywell
Board Mount Hall Effect / Magnetic Sensors
Data Sheet
Negotiable
SS511GT
SS511GT
Honeywell
Board Mount Hall Effect / Magnetic Sensors COMM SOLID STATE/MAG
Data Sheet
0-1: $1.12
1-10: $0.91
10-50: $0.76
50-100: $0.62
SS513AT
SS513AT
Honeywell
Board Mount Hall Effect / Magnetic Sensors 3.8Vdc to 30Vdc Magnet Position Sens
Data Sheet
0-1: $1.24
1-10: $1.19
10-50: $1.13
50-100: $1.04
SS513GT
SS513GT
Honeywell
Board Mount Hall Effect / Magnetic Sensors COMM SOLID STATE/MAG
Data Sheet
0-1950: $1.11
1950-2000: $0.98
2000-5000: $0.88
SS51GT
SS51GT
Honeywell
Board Mount Hall Effect / Magnetic Sensors COMM SOLID STATE/MAG
Data Sheet
0-1: $1.00
1-10: $0.88
10-100: $0.80
100-250: $0.73
