Product Summary
The NMA0509SC is a power solutions DC/DC converter. It is the standard building block for on-board distributed power system. The NMA0509SC is ideally suited for providing dual rail supplies on primarily digital boards with the added benefit of galvanic isolation to reduce switching noise. All of the rated power may be drawn from a single pin provided the total load does not exceed 1watt.
Parametrics
The NMA0509SC absolute maximum ratings: (1)Short-circuit duration: 1 second; (2)Internal power dissipation: 450mW; (3)Lead temperature 1.5mm from case for 10 seconds: 300℃; (4)Input voltage VIN: 7V.
Features
The NMA0509SC features: (1)Wide Temperature performance at full 1 Watt load, –40℃ to 85℃; (2)Dual Output from a Single Input Rail; (3)Industry Standard Pinout; (4)Power Sharing on Output; (5)1kVDC Isolation; (6)Efficiency to 78%; (7)UL 94V-0 Package Material; (8)No Heatsink Required; (9)Internal SMD Construction; (10)Toroidal Magnetics; (11)Fully Encapsulated; (12)No External Components Required.
Diagrams
Image | Part No | Mfg | Description | ![]() |
Pricing (USD) |
Quantity | ||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
![]() NMA0509SC |
![]() Murata Power Solutions |
![]() DC/DC Converters 5V to +/-9V +/-55mA SIP |
![]() Data Sheet |
![]()
|
|
||||||||||||
