Product Summary

The 2SD1264 is a Power Transistor.

Parametrics

2SD1264 absolute maximum ratings: (1)Collector to base voltage, VCBO: 200V; (2)Collector to emitter voltage: 150V; (3)Emitter to base voltage, VEBO: 6V; (4)Peak collector current, ICP: 3A; (5)Collector current, IC:2A; (6)Collector power dissipation: 30W; (7)Junction temperature: 150℃; (8)Storage temperature: –55 to +150℃.

Features

2SD1264 features: (1)High collector to emitter VCEO; (2)Large collector power dissipation PC; (3)Full-pack package which can be installed to the heat sink with one screw.

Diagrams

2SD1264 circuit

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
2SD1264
2SD1264

Other


Data Sheet

Negotiable
2SD1264A
2SD1264A

Other


Data Sheet

Negotiable
2SD1264AP
2SD1264AP


TRANS NPN LF 180VCEO 2A TO-220F

Data Sheet

Negotiable
