Product Summary

The 125LS22-R is an AC Line Rated Disc Capacitor. It is specifically designed and tested for use on 125 Volt through 600 Volt AC power sources. Certified to meet demanding X & Y type worldwide safety agency requirements, they are applied in across-the-line, line-to-ground, and line-by-pass fi ltering applications. The 125LS22-R offers the most complete selection in the industry—six product families—exactly tailored to your needs.

Parametrics

125LS22-R specifications: (1)Application Voltage Range(Vrms 50/60 Hz): 250; (2)Dielectric Strength(Vrms 50/60 HZ for 1 minute): 2000; (3)Dissipation Factor (Maximum): 2%; (4)Insulation Resistance (Minimum): 1000 ΩF; (5)Mechanical Data: Service Temperature 125℃ Maximum; Coating Material per UL94V0; (6)Temperature Characteristics: Y5V.

Features

125LS22-R features: (1)Worldwide Safety Agency Recognition: Underwriters Laboratories - UL1414 & UL1283; Canadian Standards Association - CSA 22.2 No. 1 & No. 8; European EN132400 to IEC 384-14 Second Edition; (2)Required In AC Power Supply and Filter Applications; (3)Six Families Tailored To Specific Industry Requirements; (4)Complete Range of Capacitance Values.

Diagrams

125LS22-R diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
125LS22-R
125LS22-R
Vishay/Cera-Mite
Ceramic Disc Capacitors 250V 0.022uF 20%
Data Sheet
0-1: $1.49
1-10: $1.19
10-25: $0.96
25-50: $0.88
